Broadcom MegaRAID 9520-8i PCIe 4.0 8-Port NVMe/SAS/SATA RAID Controller | Tri-Mode | 05-50134-25

Broadcom MegaRAID 9520-8i PCIe 4.0 8-Port Tri-Mode NVMe/SAS/SATA RAID Controller – 05-50134-25

The Broadcom MegaRAID 9520-8i is part of the industry's first PCIe Gen4 RAID adapter family. Featuring Tri-Mode SerDes technology, it supports NVMe, SAS, and SATA drives simultaneously on the same controller — delivering twice the performance of previous generation controllers with the flexibility to mix drive types in a single drive bay.

Key Specifications

• Part Number: 05-50134-25
• Model: MegaRAID 9520-8i
• Interface: PCIe 4.0 x8
• Ports: 8 internal (1 × SFF-8654 connector)
• SAS Speed: 12Gb/s SAS / 6Gb/s SATA / NVMe PCIe Gen4
• RAID Levels: JBOD, 0, 1, 10 (iMR entry RAID firmware — no RMRR)
• Form Factor: PCIe plug-in card (low-profile)
• Typical Power: 6.0W
• MTBF: >5,000,000 hours at 40°C
• Warranty: 3 years

Tri-Mode Technology

• Supports NVMe, SAS, and SATA devices in a single drive bay simultaneously
• Compatible with U.2 (SFF-8639) backplanes and U.3 (SFF-TA-10001) via Universal Backplane Management
• iMR firmware — no host memory reservation (RMRR) required, ideal for UEFI-restricted platforms
• Managed via LSI Storage Authority (LSA), StorCLI, and HII (UEFI)

OS Support

Windows Server, VMware vSphere/ESXi, Red Hat Enterprise Linux, SUSE Linux, Ubuntu, CentOS, Debian, Oracle Enterprise Linux, Fedora, FreeBSD, Citrix XenServer

Contact us for pricing and availability in Qatar.
