Broadcom MegaRAID 9520-8i PCIe 4.0 8-Port Tri-Mode RAID Controller – 9520-8I (OEM)

The Broadcom MegaRAID 9520-8i (OEM/bare model) is identical in functionality to the 05-50134-25 retail variant — a PCIe Gen4 Tri-Mode RAID controller supporting NVMe, SAS 12Gb/s, and SATA 6Gb/s devices simultaneously via a single SFF-8654 connector. Part of the MegaRAID 9500 Series — the industry's first PCIe Gen4 RAID adapter family.

Key Specifications

• Model: MegaRAID 9520-8i
• OEM Part: 9520-8I
• Interface: PCIe 4.0 x8
• Ports: 8 internal (1 × SFF-8654 / SlimSAS connector)
• Drive Support: NVMe PCIe Gen4, 12Gb/s SAS, 6Gb/s SATA (Tri-Mode)
• RAID Levels: JBOD, 0, 1, 10
• Form Factor: Low-Profile PCIe plug-in card
• Typical Power: 6.0W
• Dimensions: 155.52mm × 68.77mm

Tri-Mode Technology

• NVMe, SAS, and SATA drives operable concurrently in the same enclosure
• U.2 and U.3 backplane compatible
• iMR firmware — no RMRR host memory reservation required
• Management: LSI Storage Authority (LSA), StorCLI CLI, HII UEFI
• MegaRAID SafeStore for SED key management

OS Support

Windows Server, VMware vSphere/ESXi, RHEL, SUSE, Ubuntu, CentOS, Debian, Oracle Enterprise Linux, Fedora, FreeBSD, Citrix XenServer

Contact us for pricing and availability in Qatar.
