High-bandwidth 50/125µm OM4 multimode fiber patch cable with LC duplex connectors. Optimised for 10GbE, 25GbE, and 40GbE SFP+ / QSFP+ transceivers in server and switch applications. Available in Qatar.
Key Specifications
Fiber Type: OM4 — 50/125µm Multimode
Connector: LC/UPC Duplex — both ends
Jacket: LSZH (Low Smoke Zero Halogen) — Aqua
Bandwidth: 4700 MHz·km (850nm)
Max Distance: 100m @ 10GbE | 70m @ 40/100GbE
Insertion Loss: ≤ 0.3 dB per connector
Lengths Available: 1m, 3m, 5m, 10m, 15m, 30m
Applications
SFP+ 10GbE transceiver connections
QSFP+ 40GbE / QSFP28 100GbE links
Server-to-switch datacentre cabling
Short-range intra-rack and inter-rack links
Send your RFQ with quantity and lengths to sales@serverparts.qa.
